Solution Intro
The GS-Smart Farm Mounting System (Flat Type) is an advanced solar mounting solution tailored for agricultural environments requiring ample sunlight transmission and large-span clearances. Constructed entirely from high-strength aluminum alloy (excluding the foundation), it offers lightweight durability, easy installation, and customizable configurations to suit different shading, span, and clearance needs.
This system is ideal for dual-use agricultural lands, allowing crops and solar generation to coexist efficiently. It supports a maximum span of over 5 meters, facilitating the movement of large agricultural machinery and ensuring operational convenience in the field. Backed by a 10-year warranty, the system offers lasting performance and quick return on investment.
Technical Specifications
| Category | Specification |
|---|---|
| Installation Site | Ground |
| Segment Tilt Angle | 0–20° |
| Inclined Angle | 0–15° |
| Construction Height | <4m |
| Material | High-strength aluminum alloy & A2-70 |
| Color | Silver or customized |
| Surface Treatment | Anodizing or electrophoresis |
| Maximum Wind Speed | <60m/s |
| Maximum Snow Cover | <200cm |
| Flat Type Span | 3000mm–5000mm |
| Slope Type Span | 3000mm–3600mm |
| Foundation | Concrete foundation, Ground screw foundation |
| Reference Standards | ASCE7-10 / EN1991 / AS/NZS1170 / OTHER |
| Warranty | 10 Years |
Key Features
- Large Span Design: Maximum span exceeds 5 meters, allowing easy passage of large agricultural machinery and facilitating efficient field operations.
- Fast Installation: Screw pile foundation enables short construction periods with minimal impact on farmland.
- Efficient Assembly: Simplified joint connections significantly improve installation efficiency.
- Light Transmission Optimization: Designed to balance solar energy generation with adequate sunlight for crops.
- Customizable Layout: Span, clearance, and shading ratio can be tailored to meet project-specific requirements.
Application Scenarios
- Flat agricultural land with crop and energy co-utilization
- Agro-PV integration projects requiring wide access for machinery
- High-efficiency solar farms on farmland
- Farms seeking reduced shading and flexible solar layouts
Enquiry Now
Need a wide-span and easy-to-install solar mounting system for your farmland?
✅ 5m+ span for large machinery
✅ Lightweight and corrosion-resistant aluminum
✅ Quick screw foundation installation
✅ 10-year system warranty
