T-Style Solar Structure for Maximum Coverage and Efficiency
The Single Column Single T solar carport from Carport Structures Corporation is a high-efficiency parking structure engineered for dual-side coverage while maintaining a minimal footprint. Using a central column with cantilevered arms on both sides, this T-style configuration supports two rows of vehicles per bay while maximizing open driving and parking space.
Designed with solar panel integration in mind, this structure is ideal for large-scale solar energy systems in commercial, industrial, municipal, and institutional settings.
🔧 Design & Engineering Criteria
- Wind Load: Minimum 90 MPH
- Snow Load: Minimum 30 psf
- Compliance: Meets all applicable federal, state, and local building codes
- Tilt Angle: Fixed tilt standard up to 5º (optional up to 10º)
🏗️ Structural Components
COLUMNS:
- Material: HSS ASTM A-500 Grade B
- Coating Options: Primed or Hot-Dip Galvanized
BEAMS:
- Type: Miscellaneous or Wide Flange
- Material: A-992 Grade 50 Structural Steel
- Coating Options: Primed or Hot-Dip Galvanized
PURLINS:
- 16-gauge Cold Rolled G-90 Galvanized Steel
RACKING SYSTEM:
- Cold-formed Z or hat-shaped section
- 16-gauge G-90 galvanized steel
- Pre-punched to fit selected solar module patterns
✅ Standard Features
- Single central column with dual-side cantilevered coverage
- Pre-punched solar racking ready for module installation
- Fixed tilt up to 5º for optimal solar exposure
- Full hot-dip galvanizing or primer coating
- Tailored bay size and layout for site-specific requirements
✨ Optional Upgrades
- Fixed tilt increase to 10º
- 1’ end overhangs for added coverage
- Steel roof sheeting for weather protection
- Soffit under-sheeting for clean, finished appearance
☀️ Built for Solar. Built to Last.
The Single Column Single T carport style is built for performance in high-volume installations. With direct-mount racking, this structure reduces solar installation time and ensures long-term system durability. Its open layout and sleek design make it a preferred choice for facilities looking to add value, shade, and solar energy generation—all in one solution.
📩 Request a Custom Quote Today
Looking for a smart, solar-ready carport design that balances form and function? Contact us today to receive a customized quote for the Single Column Single T system, tailored to your project’s solar requirements, site layout, and preferred panel specifications.
